MPPT 60AMP Solar Charge Controller For 12V 24V 36V 48V DC Battery Regulator

Feature: *Fit for USER(can be set Lithium Lifepo4 Li(NiCoMn)O2)/Vented/Flooded/Sealed/Gel/NiCd battery.User programmable for absorption voltage/Floating voltage/Low voltage disconnect./Load Timer.Real-time energy recording. *Blacklight LCD Dispaly PV voltage/output power/Battery voltage/charging current/working mode/Temperature TROUBLESHOOTING function and LCD display and can help users not only check the whole system operating data and statuses but also quickly identify system faults and modify parameters. *Intelligence Fan-on temperature >45 and off < 40 Porous heat dissipation.and fan use BEARING technologies increase life UP TO 5000hrs in normal use. *Charging 3-stage: constant current(MPPT) constant voltage(Absorption Voltage) floating charge *Selectable battery type Vented / Sealed / Gel / NiCd / Lithium battery (default is Sealed) (defined voltage for other battery by user) *Soft start time ≤1S Dynamic response and recovery time 100us *Max efficiency ≥98.1% PV utilization ≥99% *In order to reduce the cost of electricity caused by high current PV and battery each have two terminals MULTIPLE ELECTRONIC PROTECTIONS Short-circuting Reverse-current Overcharging Overload Over-discharging Reverse polarity protection Notes: The output terminal is for lamp only( 12V system less 60W 24V/36V/48V system less 100W ) and it will be burnt if connecting to other loads. The output for battery is no polarity reverse protection. Remarks: 1. The maximum PV input voltage (Voc): DC160V (The controller can not work with this long duration voltage which will interrupt the controller. Refer to the input voltage of PV). 2. The output port is only for lamps (12V system less 60W 24V/36V/48V system less 100W) and will be burned if connected to other loads. The battery output is not reverse polarity protection. 3. Always connect the battery first!!! Make sure the battery voltage is sufficient for the controller to recognize the correct system voltage. The order of dismantling contradicts the order of wiring. 4. Do not connect any inverter/wind/generator or charger to the controller please connect the inverter to the battery side. 5. Ensures the solar input voltage exceeds 3V or more than the battery and the total input power exceeds the max. the charging current is almost zero when the controller has trickle charge. Specification MPPT controller model: HHJ-60A Rated current: 60A Charging mode: MPPT automatic maximum power point tracking Charging method: three stages: constant current (MPPT) constant voltage floating charge System type: DC12V/24V/36V/48V automatic identification System identification voltage: DC9V-DC15V (12V system) DC18V-DC29V (24V system) DC30V~DC39V (36V system) DC40V-DC60V (48V system) Soft start time: ≤1S (12V/24V/36V/48V system) Dynamic response recovery time: 100us (12V/24V/36V/48V system) Machine efficiency: ≥98.1% (12V/24V/36V/48V system) Photovoltaic module utilization rate: ≥99% (12V/24V/36V/48V system) MPPT working voltage and range: PV open-circuit voltage recommended input voltage: DC20V-DC80V (12V system) PV open-circuit voltage recommended input voltage: DC37V-DC105V (24V system) PV open-circuit voltage recommended input voltage: DC50V-DC160V ( 36V system) PV open circuit voltage input voltage recommended value: DC72V-DC160V (48V system) Maximum limit input voltage (VOC): DC150V (12V/24V/36V/48V system) Maximum solar panel input power: 720W (12V system) 1440W (24V system) 2100W (36V system) 2800W (48V system) Packing list: 1*MPPT solar controller
