MONGOOSE Women's 27.5 F Switchback Sport - Navy Mountain Bike

Infused with over 40 years of experience and pedigree, the Switchback was designed with everything a rider needs to take on single track trails or put in mile after mile on crushed gravel paths – all at an excellent value.
Tectonic® T1 aluminum frame for lightweight durability
Mongoose® MTB saddle keeps you comfortable on long rides
27.5” tires provide a stable and smooth ride
Internal cable routing allows for neat, clean lines while providing added protection
Disc brakes offer superior stopping power you can count on in all riding conditions
SPECIFICATIONS
FRAME - Tectonic T1, aluminum, 27.5" sport geometry, internal cable routing, 9 mm x 135 mm dropout, replaceable hanger
FORK - Xposure, 27.5", steel steerer, lockout, 9 mm x 100 mm, QR, 80 mm travel
CRANK - Prowheel TM-CY10, aluminum, 36/22T
CHAIN - KMC Z8
BOTTOM BRACKET - Feimin FP-B609W, cartridge, 3-piece, threaded 73 mm shell
SHIFTERS - Shimano SL-M315, 2 x 8
REAR COG - Sunrace, 8-speed, 11-34T
FRONT DERAILLEUR - Shimano FD-M315, band clamp
REAR DERAILLEUR - Shimano RD-TX800
RIMS - Xposure MD-16, aluminum double wall, 19 mm ID, 32H
FRONT HUB - Xposure, aluminum, ball bearing, 9 mm x 100 mm, 32H, 6-bolt
REAR HUB - Xposure, aluminum, ball bearing, 9 mm x 135 mm, 32H, 6-bolt
SPOKES - 14G, stainless steel
TIRES - Xposure MTB, 27.5 in x 2.1 in, wire bead
PEDALS - Mongoose, nylon
BRAKES - Mongoose, mechanical, aluminum, 160 mm rotor
HANDLEBAR - Xposure, double-butted aluminum, 680 mm width, 25 mm rise, 31.8 mm clamp
STEM - Xposure diecast, threadless, 70 mm/90 mm, 7°, 31.8 mm clamp
HEADSET - Threadless, ZS44/ZS44, retainer bearing
SEAT POST - Xposure, aluminum, 350 mm, 20 mm offset, 31.6 mm
SADDLE - Mongoose MTB comfort, steel rails
GRIPS - Xposure Kraton, single density
GEOMETRY & SIZING
W SM
W MD
A
HEAD TUBE ANGLE (DEGREES)
70
70
B
SEAT TUBE ANGLE (DEGREES)
73
73
C
HORIZONTAL TOP TUBE LENGTH (MM)
555
565
D
SEAT TUBE LENGTH (MM)
400
447
E
STANDOVER HEIGHT (MM)
670
678
F
HEAD TUBE LENGTH (MM)
110
130
G
CHAINSTAY LENGTH (MM)
435
435
H
FORK OFFSET (MM)
35
35
I
BOTTOM BRACKET DROP / RISE (MM)
46.5
46.5
J
WHEELBASE (MM)
1042
1053
K
STACK (MM)
376
380
L
REACH (MM)
658
655
STEM LENGTH (MM)
110
110
BAR WIDTH (MM)
620
620
SEAT POST SIZE (MM)
27.2
27.2
