MONGOOSE 29" Men's TYAX Sport Bike - Black

Our flagship line of performance hardtail MTBs – the Tyax series the best mountain bike has everything a rider could need to start attacking the tough climbs and winding switchbacks that come with XC riding. Available in men's 29er, women's 27.5” and a 24” youth option – not to mention multiple component spec levels – it’s easy to find the right Tyax for you.
The Tyax Sport 29er is a high performance hardtail MTB perfect for newcomers to XC trail riding. Suggested rider height by size: SM: 5’2” – 5’6”, MD: 5’5” – 5’10”, LG: 5'9" – 6'2.
Stiff, lightweight Tectonic T2 aluminum frame with tapered headtube, internal cable routing, replaceable hanger, and convertible QR dropouts.
2 x 9 Shimano Acera drivetrain with 3-piece Shimano FC-MT101 aluminum cranks.
Xposure 100 mm travel fork with steel steerer and hydraulic lockout.
29" x 2.20" Kenda Kadre tires on WTB ST-i29, aluminum double wall, tubeless compatible rims with Tektro HD-M290 hydraulic disc brakes.
SPECIFICATIONS
FRAME: Tectonic T2, aluminum, 29" cross country geometry, internal cable routing, 9 mm x 141 mm QR dropout convertible to 12 mm x 148 mm thru axle, replaceable hanger, tapered headtube
FORK: Xposure, 29", steel steerer, hydraulic lockout, 9 mm x 100 mm, QR, 100 mm travel
CRANK: Shimano FC-MT101, aluminum, 36/22T
CHAIN: KMC X9
BOTTOM BRACKET: Shimano BB-UN100, cartridge, 3-piece, threaded 68 mm shell
SHIFTERS: Shimano Acera SL-M2000, 2 x 9
REAR COG: Sunrace, 9-speed, 11-36T
FRONT DERAILLEUR: Shimano FD-M4020, side swing, direct mount
REAR DERAILLEUR: Shimano Altus RD-M2000
RIMS: WTB ST-i29, aluminum double wall, 29 mm ID, 32H, tubeless compatible
FRONT HUB: Xposure, aluminum, ball bearing, 9 mm x 100 mm, 32H, 6-bolt
REAR HUB: Xposure, aluminum, ball bearing, 9 mm x 141 mm QR, 32H, 6-bolt
SPOKES: 14G, stainless steel
TIRES: Kenda Kadre, 29 in x 2.20 in, wire bead
PEDALS: Nylon
BRAKES: Tektro HD-M290, hydraulic, aluminum, 160 mm rotor
HANDLEBAR: Xposure, double-butted aluminum, 740 mm width, 15 mm rise, 31.8 mm clamp
STEM: Xposure 3D forged aluminum, threadless, 60 mm/70 mm, 6°, 31.8 mm clamp
HEADSET: Threadless, ZS44/ZS56, retainer bearing
SEAT POST: Xposure, aluminum, 350 mm, zero offset, 31.6 mm
SADDLE: Steel railed
GRIPS: Xposure Kraton, semi-ergo lock on
GEOMETRY & SIZING
SM
MD
LG
A
HEAD TUBE ANGLE (DEGREES)
69.5
69.5
69.5
B
SEAT TUBE ANGLE (DEGREES)
74
74
74
C
HORIZONTAL TOP TUBE LENGTH (MM)
595
600
630
D
SEAT TUBE LENGTH (MM)
435
450
495
E
STANDOVER HEIGHT (MM)
773.7
785.5
813.7
F
HEAD TUBE LENGTH (MM)
110
115
120
G
CHAINSTAY LENGTH (MM)
445
445
445
H
FORK OFFSET (MM)
46
46
46
I
BOTTOM BRACKET DROP / RISE (MM)
59.5
59.5
59.5
J
WHEELBASE (MM)
1117.9
1123.3
1153.7
K
STACK (MM)
631.6
636.3
641
L
REACH (MM)
413.9
417.5
446.2
STEM LENGTH (MM)
60
80
80
BAR WIDTH (MM)
720
720
720
SEAT POST SIZE (MM)
31.6
31.6
31.6
