MONGOOSE 26 U Fireball Moto - Grey Mountain Bike

With durable Tectonic T1 aluminum construction, DJ geometry and a tapered head tube, the Mongoose Fireball Moto is ready for any pump track or big-wheeled street riding you can throw at it.
Mongoose Tectonic T1 aluminum dirtjump frame with HL VAXA 100mm travel fork.
32/14T single-speed drivetrain with Samox ISIS interface aluminum crank.
Mechanical disc brakes with long brake housing allows for bar-spins straight out of the box.
The Unifier seat post and saddle, and double wall 32H rims on 26" x 2.25" tires. Suggested for riders 5'4" to 6'2".
SPECIFICATIONS
FRAME - Tectonic T1, aluminum, Dirt Jump geometry, horizontal dropout, tapered headtube
FORK - HL VAXA 30, 26", steel steerer, 3/8" x 100 mm, nutted, 100 mm travel
CRANK - Samox, ISIS Interface, 32T steel chainring
CHAIN - KMC S1
BOTTOM BRACKET - Cartridge, cartridge, ISIS axle, 68mm
REAR COG - Single-speed, 14T cog
RIMS - Aluminum single wall, 29mm ID, 32H
FRONT HUB - Aluminum, ball bearing, 3/8 in axle, 32H
REAR HUB - Aluminum, ball bearing, 3/8 in, 32H, 135mm, disc mount
SPOKES - 14G, steel, chrome
TIRES - 26 in x 2.25 in, wire bead
PEDALS - Mongoose, nylon
BRAKES - Mechanical disc, 160mm rotor
HANDLEBAR - Mongoose, aluminum, 750 mm width, 30 mm rise, 31.8 mm clamp
STEM - Mongoose, threadless, 45 mm
HEADSET - Threadless, ZS44/ZS56, retainer bearing
SEAT POST - Aluminum, 200 mm, 27.2 mm
SADDLE - Mongoose, steel rails
GRIPS - Xposure Kraton, single density
SIZES - One size
GEOMETRY & SIZING
FIREBALL SS
FIREBALL 9-SPEED
FIREBALL MOTO
A
HEAD TUBE ANGLE (DEGREES)
69
69
69
B
SEAT TUBE ANGLE (DEGREES)
70
70
70
C
HORIZONTAL TOP TUBE LENGTH (MM)
585
585
612
D
SEAT TUBE LENGTH (MM)
292
292
324
E
STANDOVER HEIGHT (MM)
680
680
697
F
HEAD TUBE LENGTH (MM)
115
115
115
G
CHAINSTAY LENGTH (MM)
415
415
424
H
FORK OFFSET (MM)
41
35
38
I
BOTTOM BRACKET DROP / RISE (MM)
20
20
20
J
WHEELBASE (MM)
1055
1055
1080
STEM LENGTH (MM)
43
40
45
BAR WIDTH (MM)
720
680
750
SEAT POST SIZE (MM)
27.2
27.2
27.2
