MONGOOSE 24 U Switchback - Navy Mountain Bike

The Switchback is designed for a younger rider looking for a well-rounded, comfortable, and capable mountain bike. The Switchback gives you more than enough bike to take on single track trails or put in mile after mile on crushed gravel paths – all at an excellent value.
Lightweight Tectonic T1 aluminum frame, 9 x 135 mm QR dropout, and internal cable routing.
3×8 drivetrain, 3-piece aluminum cranks, and Shimano Tourney derailleurs and shifters.
Xposure 60 mm travel fork, double-butted aluminum handlebars, and mechanical disc brakes.
24" x 2.1" tires on aluminum double wall rims.
SPECIFICATIONS
FRAME - Tectonic T1, aluminum, 24" sport geometry, 9 mm x 135 mm QR dropout, internal cable routing, 9 mm x 135 mm dropout, replaceable hanger
FORK - Xposure, 24", steel steerer, lockout, 9 mm x 100 mm, QR, 60 mm travel
CRANK - Prowheel TM-CY10, aluminum, 36/22T
CHAIN - KMC Z8
BOTTOM BRACKET - Feimin FP-B609W, cartridge, 3-piece, threaded 68 mm shell
SHIFTERS - Shimano SL-M315, 2 x 8
REAR COG - Sunrace, 8-speed, 11-34t
FRONT DERAILLEUR - Shimano FD-M315, band clamp
REAR DERAILLEUR - Shimano RD-TX800
RIMS - Xposure MD-16, aluminum double wall, 19 mm ID, 32H
FRONT HUB - Xposure, aluminum, ball bearing, 9 mm x 100 mm, 32H, 6-bolt
REAR HUB - Xposure, aluminum, ball bearing, 9 mm x 135 mm, 32H, 6-bolt
SPOKES - 14G, stainless steel
TIRES - Xposure MTB, 24 in x 2.1 in, wire bead
PEDALS - Mongoose, nylon
BRAKES - Mongoose, mechanical, aluminum, 160 mm rotor
HANDLEBAR - Xposure, double-butted aluminum, 680 mm width, 25 mm rise, 31.8 mm clamp
STEM - Xposure diecast, threadless, 60 mm, 7°, 31.8 mm clamp
HEADSET - Threadless, ZS44/ZS44, retainer bearing
SEAT POST - Xposure, aluminum, 350 mm, 20 mm offset, 31.6 mm
SADDLE - Mongoose MTB comfort, steel rails
GRIPS - Xposure Kraton, single density
SIZES - One size
GEOMETRY & SIZING
24"
20"
A
HEAD TUBE ANGLE (DEGREES)
70
70
B
SEAT TUBE ANGLE (DEGREES)
72
73
C
HORIZONTAL TOP TUBE LENGTH (MM)
530
445
D
SEAT TUBE LENGTH (MM)
290
255
E
STANDOVER HEIGHT (MM)
606
524
F
HEAD TUBE LENGTH (MM)
90
90
G
CHAINSTAY LENGTH (MM)
430
370
H
FORK OFFSET (MM)
40
40
I
BOTTOM BRACKET DROP / RISE (MM)
38
40
J
WHEELBASE (MM)
1007
876
K
STACK (MM)
506
418
L
REACH (MM)
366
317
STEM LENGTH (MM)
70
70
BAR WIDTH (MM)
700
560
SEAT POST (MM)
27.3
27.4
