MKS LCD12864B Intelligent LCD Display Smart Display 3D Printer Part

Features Integrated PCB whose display quality is better than traditional screen Anti static ability is up to 4KV With SD card slot for easily printing Equipped with its own encoder parameter setting Support MKS series and ramps motherboard via modifying firmware Multi language display set by marlin firmware Manual and firmware download address please copy the following link to browser Github Link https github com makerbase mks tab repositories Note MKS LCD12864B Specially developed to work with MKS SGen L MKS Robin Lite3 and SKR series board Marlin Enable Setting 1 Screen Contrast SettingFollow processes Arduin Libraries U8glib Utility to find out u8g dev uc1701 mini12864 c You can install notepad to check this document The yellow frame below is screen contrast the contrast will change as the figure value increasesor reduces Default value is 0x027The contrast value of LCD12864A is 0x0322 Screen EnableThe same as mini 12864 the enable item yellow highlighted Note The firmware can match one type of screen only It may cause display error if setting up several types of screen If the firmware is enabled and refreshed but the screen display is blurred or not displayed The reason this may be caused is that there is no contrast setting or no saving Simply set the contrast to 0x032 save it and re use arduin to update the firmware Modify screen contrast in Marlin 2 0 1 Enable the define MKS MINI 12864 in configuration h2 In the Conditionals post
