MK3-M4 MK4-M4 MK6-M4 Interface Board MACH4 USB CNC Motion Control Card 3/4/6 Axis Motion Controller

Description MK3 M4 MK4 M4 MK6 M4 Interface Board MACH4 USB CNC Motion Control Card 3 4 6 Axis Motion ControllerSpecifications Product NameMKX M4 Motion Control CardAxis Output ControlDrive Current Isolated open collector output 5V 20mA Drive Pulse direction output Output frequency 2000KHZ Isolation Voltage 3 5KV AxisMK3 M4 3 axisMK4 M4 4 axisMK6 M4 6 axis Spindle Inverter OutputAnalog voltage output 0 10VPWM output 5V 1KHZ Duty 0 100 Pulse direction output 5V 15HZ to 4KHZ 8 IO OutputDrive Current Isolation 50mA 25VIsolation Voltage 3 5KV16 IO InputInput Current Isolated inputs 5 mA maximum voltage 25V Isolation Voltage 3 5KV USB InterfaceComplies with USB2 0 standardSize184 127 30mmQuantity1 Set MK M4 Motion Control CardManualClick to checkMore to search MACH3 USB ID 1742678MACH3 Ethernet Port ID 1742681 Features 1 Dual Processors ARM FPGA More processing power2 Support all versions of Mach4 3 Work under Windows 32 bit operating system 4 Support spindle speed feedback function 5 USB jack does not need to install the driver plug and play under all versions of Windows 6 Full support USB hot swappable USB connection status monitoring at any time Under Mach3 working state USB cable unplugs and then plugs in but also the normal connection 7 Supports 3 axis linkage 8 Maximum step pulse frequency is 2000 KHz can connect servo driver and stepper driver 9 The indicator light indicates various working status such as USB connection Mach3 connection an
