MESTEK Intelligent Multimeter DM90A/DM90S High Speed Automatic Smart Multimeter Anti-burning NCV True RMS Digital Multimetro
Technical Details
AC Current: | 60mA/600mA/10A |
AC Voltage: | 6V/60V/600V |
Anti-drop rubber sleeve: | Yes |
Backlight: | Yes |
Brand Name: | MESTEK |
Cathode display: | Yes |
continuity test: | Yes |
DC Current: | 60mA/600mA/10A |
DC Voltage: | 600mV/6V/60V/600V |
Dimensions: | 147*71*45mm |
Diode test: | Yes |
Display Type: | Digital Display |
DIY Supplies: | Electrical |
Flashlight: | Yes |
Frequency: | 60/600/6K/60K/600K/10M |
Keeping data: | Yes |
Low voltage display: | Yes |
Measuring Capacitance Range: | 60nF/600nF/6uF/60uF/600uF/6mF/100mF |
Measuring Inductance Range: | none |
Measuring Resistance Range: | 6000ohm/6Kohm/60Kohm/600Kohm/6Mohm/60Mohm |
Model Number: | DM90A |
NCV: | 90~1000V AC light and sound alarm |
On and off test: | Buzzer and lighting |
Operating Mode: | Auto range |
Operating Temperature: | 0 - 40 ℃ |
Power Supply: | 3*1.5V AAA Batteries(Not Included) |
Protection against burn: | less than 250V 600mA/10A |
Sampling Rate: | 3 times/s |
Thermocouple measure temperature: | -20℃~1000℃/-4°F~1832°F |
True RMS: | Yes |
