MAX30100 Heart Rate Sensor Module Heartbeat Sensor Oximetry Pulse OximeterUltra-Low Power Consumption

More document click to download MAX3010Overview The MAX30100 is an integrated pulse oximetry and heart rate monitor sensor solution It combines two LEDs a photodetector optimized optics and low noise analog signal processing to detect pulse oximetry and heart rate signals The MAX30100 operates from 1 8V and 3 3V power supplies and can be powered down through software with negligible standby current permitting the power supply to remain connected at all times Applications ● Wearable Devices● Fitness Assistant Devices● Medical Monitoring DevicesFeatures ● Complete Pulse Oximeter and Heart Rate SensorSolution Simplifies Design Integrated LEDs Photo Sensor andHigh Performance Analog Front End Tiny 5 6mm x 2 8mm x 1 2mm 14 Pin OpticallyEnhanced System in Package● Ultra Low Power Operation Increases Battery Life forWearable Devices Programmable Sample Rate and LED Current forPower Savings Ultra Low Shutdown Current 0 7µA typ ● Advanced Functionality Improves MeasurementPerformance High SNR Provides Robust Motion Artifact Resilienc Integrated Ambient Light Cancellation High Sample Rate Capability Fast Data Output CapabilityPackage Included 1 x MAX30100 Heartbeat Sensor Module
