MAVLink Wifi Bridge 2.4G Wireless Wifi Telemetry Module with Antenna for Pixhawk APM Flight Controller
![MAVLink Wifi Bridge 2.4G Wireless Wifi Telemetry Module with Antenna for Pixhawk APM Flight Controller](http://imgaz.staticbg.com/images/oaupload/banggood/images/9F/26/ebe6fd83-ace6-479f-b468-1410a23730eb.jpg)
PIXHAWK
sku: 1428590
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$8.87
Shipping from: China
Description
MAVLink Wifi Bridge 2.4G Wireless Wifi Telemetry Module with Antenna for Pixhawk APM Flight Controller Instruction: It support Mobile Computer and can replace the 3DR data transmission module and free you from the limitation of USB cable. It is suitable for all flight control with TTL interface. Specification: Wireless Module: FCC compliant Wifi standard: 802.11 b/g/n Frequency Range: 2.4G-2.5G (2400M-2483M) Size: 18.5 x 26mm Suitable For: Pixhawk, APM2.5/2.6, Mini APM Version: APM Version/ Pixhawk Version APM Version is compatible with APM, Mini APM Flight Controller Pixhawk Version is compatible wiht Pixhawk Flight Controller Transmit power: - 802.11 b: +20dBm - 802.11 g: +17dBm - 802.11 n: +14dBm Receive power: - 802.11 b: -91dBm (11Mbps) - 802.11 g: -75dBm (54Mbps) - 802.11 n: -72dBm (MCS7) Connect data: - SSID: ALPHAUAVLINK - Code: alphauavlink - Ground stataion IP: 192.168.4.1 - Protocol: UDP - Braud: 921600 Usage: For PIXHAWK: 1. If connected to Serial1/Telem1 these parameters should be set on the flight controller (if using another telemetry port, replace the "1" in the parameter name with the telemetry port's number): 2. SERIAL1_PROTOCOL = 2 (MAVLink2) or 1 (MAVLink1) 3. SERIAL1_BAUD = 921 (921600 baud) 4. If you have problems connecting, it may help to set BRD_SER1_RTSCTS = 0 to disable flow control although this is not normally necessary Connecting from a Ground Station. 5. On your PC, open the wifi network connections screen and select the wifi access point (normally "ALPHAUAVLINK" or "alphauavlink") 6. On the ground station, set the connection type to UDP and press "Connect" 7. If all is well the ground station will connect, download parameters 8. If you have problems connecting, it may help to set BRD_SER1_RTSCTS = 0 to disable flow control although this is not normally necessary FOR APM: 1. Directly insert in the flight contorl's data transimission port. When powered there will be a wifi named ALPHAUAVLINK, the password is alphauavlink. If connect successfully, it will distribute you an IP address 192.168.4.1. 2. Start borwser and type in the browser's address bar "192.168.4.1" Then press Setup, changing baudrate to 57600, press SAVE, reboot APM flight control. 3. Turn on ground station software, set connect as UDP protocol, 57600 braud, 14500 connect port. Noting: 1. Operating voltage: 4V to 7V, maximum support to 12V, but this time it would be more serious fever. 2. Working current: average current 0.11A, around the peak 0.2A, if connected to the flight control of other external devices more (such as GPS, OSD, head, etc.) the best flight control through the power management module powered by electricity supply If transfer for APM flight control, the total current only to about 0.5A. Package Included: 1 x 2.4G Wifi Telemetry Module 1 x Antenna 1 x Shielding Case 1 x APM wire or pixhawk wire
