MATEKSYS F411-MINI SE Flight Controller OSD 5V/2A MPU6000 2~8S VTX Powre Switch 30.5mm/20mm for RC Drone

MATEKSYS F411 MINI SE Flight Controller OSD 5V 2A MPU6000 2 8S VTX Powre Switch 30 5mm 20mm for RC DroneSpecification Flight ControllerBrand name MATEKSYSMCU 100MHz STM32F411CEU6IMU MPU6000 SPI Baro BMP280 I2C OSD AT7456E SPI Blackbox No2x Uarts2x Softserial Tx6x PWM outputs Dshot Proshot oneshot multishot 1x I2C3x ADC VBAT Current RSSI 3x LEDs for FC STATUS Blue Red and 3 3V indicator Red 1x SH1 0 8pin connector Vbat G Curr R6 S1 S2 S3 S4 TR SA VTX control YesCamera control YesWS2812 Led control YesBeeper output YesRSSI YesFiltered Vbat output power for VTX Switchable via AUX modes tab user1 Convertible 20mm to 30 5mm mountingPowerInput 6 36V 2 8S LiPo BEC 5V 2A cont Max 3A LDO 3 3V Max 200mABattery Voltage Sensor 1 10 Scale 110 No Current Sensor built in supports external current sensor of PDB 4in1FC FirmwareINAVTarget MATEKF411SEBF unified Target MATEKF411SE MTKS PhysicalMounting20 x 20mm 3mm with Silicon Grommets20 x 20mm 2mm with SiliconBrass Grommets30 5 x 30 5mm 3mm with Conversion Plate and Silicon GrommetsDimensions 28 x 28 mmWeight 5gIncluding1x F411 miniSE1x 20mm to 30 5mm conversion plate6x Silicon grommets M4 to M36x Brass grommets M3 to M21x SH1 0 8pin cable 5cm2x SH1 0 8pin connectorsFirmware Download
