MATEKSYS CRSF-PWM-C CRSF to PWM Converter 10 PWM 50-400Hz Output 2 UARTs Bulit-in Current Sensor Failsaft Auto Set for R

MATEKSYS CRSF PWM C CRSF to PWM Converter 10 PWM 50 400Hz Output 2 UARTs Bulit in Current Sensor Failsaft Auto Set for RC ReceiverSpecifications Brand Name MATEKSYSItem Name CRSF PWM C ConverterModel CRSF PWM CWeight 2 8gSize 26x26mmCompatible with CRSF protocol receiver only10x PWM outputsPWM frequency configurable 50Hz default 100 160 330 400Hz 2x UARTs for Receiver and GPS Telemetry ID RxBt Curr Capa Bat GPS GSpd Hdg Alt Sats36V Max battery voltage sense 1K 10K voltage divider built in Current sensor built in 90A continuous 220A Peak current scale 150 by defaultVbat and Current sensor scale configurableFailsafe value auto setFirmware upgradeableRated voltage 4 9V 5V pad 0 36V BAT No 5V regulator built inPinouts and Pads Tx1 Rx1 UART1 for CRSF protocol ReceiverTx2 Rx2 UART2 for GPS firmware update setting parameters1 10 CH1 CH10 PWM outputsCurr current sensor signal 0 3 3V Vbat Battery voltage sensing 0 36V G ground4v5 pad voltage 5V pad voltage 0 3V make sure the voltage on 5V pad is not higher than receiver and GPS rated voltage Failsafe Failsafe value is set automatically after CRSF PWM board is powered on and receive CRSF signal LED blinks 8 times quickly Failsafe value The PWM value of each channel except CH3 when CRSF signal is received by CRSF PWM board for the first timeCH3 is specially arranged for the throttle Failsafe value 988 by default Usually put the Throttlejoystick to the lowest point put AIL Roll E
