M5Stack Cap LoRa 1262 for Cardputer Adv LoRaWAN Module SX1262 GPS Antenna 868-923MHz High Precision GNSS Positioning IoT

Specifications LoRa Module SX1262Frequency Range 868 923 MHzMaximum Data Rate 300 kbpsLoRa Interface SPILoRa Antenna Dimensions 108 9 3 mm SMA connector internal hole 3 dBi gainOutput Power 22 dBmReceiving Sensitivity 147 dBm low rate LoRa mode Operating Voltage DC 5V 163 4 mACommunication Modes FSK GFSK MSK LoRa OOKGPS Module ATGM336H 6NAT6668GPS Interface UART default 115200bps 8N1Satellites Systems Supported GPS QZSS BD2 BD3 GAL GLOBDS B1I B1CFrequency Bands GPS QZSS SBAS L1 GALILEO E1 GLONASS R1Channels 50 channelsPositioning Accuracy 1 5 m CEP50 Position Update Frequency Max 10 HzProtocol NMEA 0183 4 1GPS Sensitivity Tracking 162 dBmAcquisition 160 dBmCold Start 148 dBmStartup Times Cold Start 23 sHot Start 1 sPower Consumption 33 1 mAProduct Dimensions 84 0 24 0 15 2 mmProduct Weight 48 6 gFeatures 1 Wide Frequency Compatibility Operates between 868 923 MHz suitable for diverse IoT applications in various regions 2 Enhanced GPS Precision Provides sub meter accuracy 1 5 m for reliable positioning across multiple satellites systems 3 High Power Output 22 dBm LoRa transmission power ensures extended communication range for tough environments 4 Modular Antenna Design SMA connector with 3 dBi gain supports straightforward installation and secure signal transmission 5 Multi Satellites System Support Compatible with GPS QZSS BD2 BD3 GAL GLO systems ensuring global coverage for tracking and positioning Package Inc
