M5Stack ATOMS3R Development Kit ESP32-S3 0.85 Inch Screen 8MB PSRAM 128x128 IPS 6 Axis IMU & Infrared

Specifications SpecificationParameterSoCESP32 S3 PICO 1 N8R8 Dual core Xtensa LX7 up to 240MHzUSBUSB OTG USB Serial JTAGFlash8MBPSRAM8MBWi Fi2 4 GHz Wi FiTFT DriverGC9107Color IPS Resolution128 x 1286 Axis IMU BMI270 Accuracy 0 05 Accel 0 05 ° s Gyro I2C Address 0x683 Axis Geomagnetic Sensor BMM150 Accuracy 0 3 µT Mounted on BMI270 magnetometer data obtained via BMI270Infrared180 °FOV transmission distance 12 46 m unobstructed Sleep CurrentGPIO 5V supply 5 V 11 63 µAGrove 5V supply 5 V 10 75 µAUSB 5V supply 5 V 92 50 µA incl PD resistor loss Bottom GPIOG5 G6 G7 G8 G38 G39Operating Temperature0 40 ° CProduct Size24 0 x 24 0 x 12 9 mmProduct Weight6 8 g Introduction AtomS3R is a highly integrated IoT programmable controller based on the ESP32 S3 It embeds an ESP32 S3 PICO 1 N8R8 SoC with on chip Wi Fi 8MB Flash and 8MB PSRAM The device features a 0 85 inch color IPS display with a programmable button beneath it an on board 5 V to 3 3 V power a three axis BMM150 geomagnetic sensor and a six axis BMI270 IMU Power supply and firmware downloading are handled through a USB Type C connector while a HY2 0 4P port and six GPIO plus power pins on the bottom make expansion easy Compared with previous products AtomS3R is equipped with an enhanced 3D antenna that offers better performance and higher stability With dimensions of just 24 0 x 24 0 x 12 9 mm it is ideal for a variety of embedded smart device applications Features 1 Compa
