M5Stack ATOM CAN Bus Communication Unit CA-IS3050G with Isolation Anti-interference and Anti-damage

Description ATOM CAN is a CAN bus communication unit that uses the CA IS3050G transceiver solution the built in DC DC isolation power chip can effectively isolate interference and prevent damage to sensitive circuits The communication bus can support up to 110 nodes the signal transmission rate can reach 1Mbps and it has a variety of electrical line protection functions It is very suitable for application scenarios such as in vehicle transportation and security systems Product Features Adapt to ATOM Matrix ATOM LiteCAN bus multi point communicationBuilt in isolated DC DCSignal rate up to 1MbpsThe common mode voltage range is 12V to 12VProtective function Signal isolationLimitingOvervoltage protectionThermal shutdownGround loss protection 40V 40V Specification External port VH 3 96 4PCAN transceiver model CA IS3050GMaximum rate 1MbpsNumber of supported nodes 110Low loop delay 150nsCommon mode voltage 12V 12VProtection function Current limit overvoltage main dynamic timeout thermal shutdownWorking temperature 55°C 125°CNet weight 14gGross weight 33gProduct size 24 48 18mmPackage size 54 54 20mmShell material Plastic PC Package included 1 x ATOMIC CAN1 x 3 96 4P terminal1 x 120Ω terminal resistorApplication CAN bus communicationVehicle equipment controlIndustrial field controlEasyLoaderWindowsATOM CAN RECEIVEATOM CAN SENDERRelated LinksDatasheetCA IS3050GPin mapping ATOMGPIO22GPIO195VGNDATOM CANCAN TXCAN RX5VGNDExample1 Arduin0Use ATOM CAN for tra
