M5Stack® WS6812 37Pcs HEX RGB LED Hexagon LED Board with 3 GROVE Port Compatible with M5Stack UI-Flow

Description: HEX is a hexagona RGB LED panel. Total 37 RGB LEDs. With a input port and a output port, you can have mutiple of them in series connection. This is how LEDs layout in the panel. Pay attention to the sequence in your code. Product Features: Total LED: 37 Software development platform: Arduino,UIFlow(Blockly & python) Two Le go-compatible holes Package Include: 1x HEX Unit 1x Grove Cable Related Link: Offical Video Forum EasyLoader click to download EasyLoader 1.EasyLoader is a simple and fast program burner, and each product page has a product-related case program for EasyLoader. 2.After downloading the software, double-click to run the application, connect the M5 device to the computer via the data cable, select the port parameters, and click "Burn" to start burning. 3.The CP210X (USB driver) needs to be installed before the EasyLoader is burned. Click here to view the driver installation tutorial Example: 1. for Arduino IDE FastLED library on for Arduino presents excellent and colorful lighting effects. Before compile, it is require to install the FastLED library and connect HEX to GROVE A. RGB LED Library on for Arduino FastLED Library FastLED Reference(Chinese version) To get the complete code, please click here /* Install FastLED library first.(HEX is connected to GROVE A) */ #include #include "FastLED.h" #define RGB LED_PIN 21 #define NUM_LEDS 37 CRGB leds[NUM_LEDS]; uint8_t gHue = 0; void setup() { Serial.begin(115200); M5.begin(); M5.Lcd.clear(BLACK); M5.Lcd.setTextColor(YELLOW); M5.Lcd.setTextSize(2); M5.Lcd.setCursor(40, 0); M5.Lcd.println("HEX Example"); M5.Lcd.setTextColor(WHITE); M5.Lcd.setCursor(0, 25); M5.Lcd.println("Display rainbow effect"); // Neopixel initialization FastLED.addLeds/ (leds, NUM_LEDS).setCorrection(TypicalLEDStrip); FastLED.setBrightness(10); } void loop(){ fill_rainbow( leds, NUM_LEDS, gHue, 7); FastLED.show();// must be executed for RGB LED becoming effective EVERY_N_MILLISECONDS( 20 ) { gHue++; } }Copy to clipboardErrorCopied UIFlow To get the complete code, please click here. PinMap: If HEX connected to GROVE A M5Core(GROVE A) GPIO22 GPIO21 5V GND HEX Unit HEX Pin 5V GND If HEX connected to GROVE B M5Core(GROVE B) GPIO36 GPIO26 5V GND HEX Unit HEX Pin 5V GND If HEX connected to GROVE C M5Core(GROVE C) GPIO16 GPIO17 5V GND HEX Unit HEX Pin 5V GND
