M5Stack® ADC Module 16 Bit I2C GROVE ADS1100 Module 0V to 12V Analog to Digital Converter Development Board
Description: ADC integrated with ADS1100 which is a fully differential, 16-bit, self-calibrating,del ta-sig ma A/D converter. It communicates through an I2C interface,which means you can collect AD data thru PortA on M5 core from this unit to enhence your A/D performance. The I2C address is 0x48. Product Specification: COMPLETE DATA ACQUISITION SYSTEM IN A TINY SOT23-6 PACKAGE 16-BITS NO MISSING CODES INL: 0.0125% of FSR MAX CONTINUOUS SELF-CALIBRATION SINGLE-CYCLE CONVERSION PROGRAMMABLE GAIN AMPLIFIER GAIN = 1, 2, 4, OR 8 LOW NOISE: 4Vp-p PROGRAMMABLE DATA RATE: 8SPS to 128SPS INTERNAL SYSTEM CLOCK I2CTM INTERFACE POWER SUPPLY: 2.7V to 5.5V LOW CURRENT CONSUMPTION: 90A AVAILABLE IN EIGHT DIFFERENT ADDRESSES Two Le go-compatible holes Product Size: 32.5mm x 24.1mm x 10.2mm Product weight: 5.9g APPLICATION: ECG signal acquisition Blood pressure measurement Dynamometer Package Included: 1x ADC unit 1x GROVE Cable 1x HT3.96 Male Socket(2 pins) Related Link: Offical Video Forum Datasheet - ADS1100 EasyLoader click to download EasyLoader
