M-HDRE01 HDMI 2.0 Repeater 4K x 2K @ 60Hz

The HDMI Repeater transmits the signal to the display by actively regenerating the EQ value of the reconstructed signal source. It enables to boost the HDMI signal via HDMI cable up to 30M at 4k x 2k@60Hz. The special design allows the active circuitry to be powered by the HDMI cable itself that has Volts of power running through the HDMI cable.
Features
Regenerates the incoming HDMI signal by decoding and re-encoding it to a new standard HDMI signal so it can extend the transmission range without degradation.
Supports 18Gbps bandwidth, support video resolution up to 4kx2k@60Hz with the transmission distance of 30m, support YUV4:4:4.
TV refresh rate is up to 120Hz, 2 times of the transmission rate of version 1.4.
Support 12 bit deep color, Full HD, 3D.
Support CEC direct connection.
Compliant with HDCP2.2/1.4, this HDMI repeater is tested to guarantee performance and reliability.
Compatible with standard type connectors, support HDR.
No power required.
Specifications
Input InterfaceHDMI-A Female
Output InterfaceHDMI-A Female
Transmission Distance4K@60Hz up to 30m, 4K@30Hz up to 35m, 1080P up to 50m(Using HDMI CTS1.4 standard cables)
ImpedanceHDMI 100Ω
Bandwidth18Gbps(HDMI2.0)
Resolution4kx2k@60Hz, YUV4:4:4; 480i/576i/480P/576P/720P/1080i/1080P
Input level5V
PowerNo need power, HDMI input take power
Power Consumption (w)
