Lowell Manufacturing MP-1B 2U 12-Channel Passive Monitor Panel

Passive monitor panel with 12 x 1 selectable visual and aural monitoring. All twelve channels accept speaker level inputs (8 ohm or 25/70 volts) for monitoring amplifier outputs in large sound reinforcement systems. Monitoring Provides visual and aural monitoring of up to 12 lines. Inputs 1-6 Accept speaker lines (70V, 25V or 8 ohm). Inputs 7-12 Accept speaker lines (70V, 25V or 8 ohm). Visual Monitoring With precise measurement of selected speaker input via analog meter with VU and voltage scales. Subjective Aural Monitoring Subjective Aural Monitoring of selected speaker input via 3" x 5" internal speaker which may also be accessed using the monaural headphone output (stereo jack) on the front of the panel. Rackmount Chassis (2U) Steel construction finished in durable black powder epoxy. Overall size is 19"W x 3.5"H x 5.5"D. Front Panel Analog meter with VU and voltage scales, headphone jack and four control knobs for easy selection of monitored system inputs (1-6, Off, 7-12), individual speaker level inputs (1-6), individual speaker level inputs (7-12) and volume of selected input. Rear Panel Termination for input connections is made to barrier strip screw terminals which are group selectable for speaker level inputs 1-6 and 7-12 (70V, 25V or 10V for 8 ohms).
