Lowell Manufacturing MA30-RK Mixer with 30W Power Amplifier and Rackmount Kit

Mixer/amplifier with 4 ohms, 8 ohms, 25V and 70V speaker outputs at screw terminals. Includes brackets to mount to a 19" rack. Powered by 120VAC 60Hz, the main AC input is protected by a circuit breaker in back. An unswitched AC outlet in back is protected by a separate circuit breaker. The front panel features three input channels (MIC/TEL, PROGRAM, AUX1), plus BASS control, TREBLE control, power active LED and output level LED. First channel (MIC/TEL) Switchable for microphone or telephone inputs. Includes a switch to select AUX two dual combining RCA phono connectors. Includes TEL/MIC switch, which in TEL position pads the input to allow channel to be fed by a 600 ohm balanced line level telephone page port output signal. The first channel includes a MUTE ON/OFF switch. When the mute switch is turned ON, a dynamic microphone or telephone input will mute the Aux 1, Aux 3 or Program inputs. Second channel (PROGRAM) Switchable for program input screw terminals or AUX 3 dual combining RCA-phono connectors. Third channel (AUX 1) For AUX 1 dual combining RCA-phono connectors.
