Lowell Manufacturing LWBR-3532 35U Wall Rack with Base, 32" Depth, Black

Wall-mount rack swings open with a single-release grasp and pivots smoothly on internal spring-loaded hinges and stainless steel ball transfers set into the base, which adds an additional 4U to load capacity. Slam latch closure. Construction Welded 16-gauge certified U.S. steel. Black wrinkle powder epoxy finish. Beveled corners. Backbox • 4.69"D box mounts on 16" centers • Rear includes opening to accommodate wall obstructions and multiple lacing points • Sides have upper/lower EKOs for conduit (2-1/2") • Top features a removable knockout panel and combination EKOs for conduit (1/2"-3/4" and 1"-1-1/2") plus KOs for wireless antennae (1/2") • Embossed dimples and lacing points on back plane allow flush installation of board-mounted accessories Cabinet (mounting section) • Opens with single-release mechanism. Slam latch closure • Pivots open 90 degrees on support base. Right-hand swing can be changed to left using internal spring-loaded hinges • Top 10U opening has integral EIA rail for optional 19" accessories (fan panels, lights, etc.). Solid panels (shipping stiffeners) can also be used to close the top • Vents in sides and front. Center key lock allows side-byside installation • One pair 11-gauge steel rails (35U, 10-32 threaded holes, numbered RU increments) are recessed 0.63" to allow 1.38" clearance for equipment knobs and optional door. Rails are adjustable (can be moved deeper into rack) • Cabinet (mounting section) depth 27.53" Support Base • Stainless steel ball transfers in base assist smooth pivoting of loaded rack • Side EKOs (2-1/2") along base for cable management • Top access panel • Front access panel can be removed to mount equipment or accessories (4U space, 1 pr. fixed-position rails) Installation Minimum clearance to allow 90 degree swing is 49.67" (+1" for optional door). Hardware Black pilot point screws with captive washers for quick installation. Compliance EIA/TIA compliant. RoHS compliant.
