Low Level 5V 1/2/4/8 Channel Solid State Relay Module SSR G3MB-202P 240V 2A Output with Resistive Fuse for Arduino

Product description 1 5V solid state relay 240V 2A the output with a resistive fuse 240V 2A 2 Size 1 way 25 x 34 x 25 long x wide x high 2 way 55 x 33 x 25 long x wide x high 4 way 57 x 55 x 25 long x wide x high 8 Way 106 x 56 x 25 L x W x H 3 Input power 5V DC 160MA 4 The input control signal voltage High level module 0 2 5V state low level relay ON 3 3 5V state high level relay OFF Low level module 0 2 5V state low level relay OFF 3 3 5V state high level relay ON 5 There are 2 54CM pin and blue KF301 terminal control line is more convenient Input section DC Connect the power supply positive according to the relay voltage DC Connect the power supply negativeCH1 1 relay module signal trigger terminal low level trigger active CH2 2 relay module signal trigger terminal low level trigger active CH3 2 relay module signal trigger terminal low level trigger active CH4 2 relay module signal trigger terminal low level trigger active Low level trigger refers to the voltage between the signal trigger terminal and the negative terminal of the power supply is OV or the voltage of the trigger terminal is lower than the voltage of the positive terminal of the power supply When the voltage is low enough to trigger the relay is pulled in The negative side of the power supply is connected to the trigger side of a trigger so that the relay is pull Electrical parameters Voltage VersionQuiescent CurrentOperating Current Trigger VoltageTrigger Current1 ch
