Lithium Battery Pcb Bms Protection Board 3s 40a For Drill Motor Y2D1

Description: Board Size:42 * 60 * 3.4mm Continuous discharge current (upper limit): 40A (if the cooling environment is not good please reduce the load current use) Item:3S 40A 12.6V 40A lithium battery protection board (comes with recovery function-AUTO Recovery) Charging voltage: 12.6V - 13.6V Scope: Nominal voltage of 3.6V 3.7V lithium battery (including 18650 26650 polymer lithium battery) Continuous charge current (upper limit): 20A Model Number:3S 40A Product weight: 4g New upgrade version: 1 increased anti-interference function 2 reduce the large current heat by 30% 3 starting power increased from 135W to 170W (3S40A) Standard version: for starting current below 80A power 135W below the drill. Balanced version: suitable for starting current below 80A power 135W below the drill. Note 1: The successful start of the drill requires three 15C-20C power battery or six 10C-15C power battery (ordinary 18650 can not start the drill!!). Note 2: strictly according to map wiring 0V 4.2V 8.4V 12.6V do not deliberately short circuit. Note 3: When the load of the brush motor is used try to connect a non-polar capacitor (withstand voltage above 25V capacity 10uF-100uF) to the motor s positive and negative terminals to prevent the reverse spike from the motor. Break the MOS tube. Note 4: 3 groups of batteries in series please ensure that the voltage of each group of batteries if not the same please fill each battery separately and then use in series. The The Discharge test the voltage drop faster battery that group is poor battery. For some of the poor basis of electronic customers to explain: balanced charge is only auxiliary functions try not to put a good battery and poor battery mixed together! 3 sets of battery capacity / resistance closer to the better! (2 good battery +1 Poor battery use effect = 3 poor battery use effect). Enhanced version:Suitable for electric drill with starting current below 80A and power below 130W .(without balanced function) Balanced version: Suitable for electric drill with starting current below 80A and power below 170W .(with balanced charging function) Package include: 1* 3S 40A Protection Board
