Link Electronics Link ELectronics DigiFlex 1626 18W Analog Audio Power Amplifier

The 1626 is designed to take an external or an internal stereo analog audio line level signal and amplify it to an audible speaker level. The 1626 is a single module with an accompanying 1018 rear cell for use with the 1000 series audio products. The audio source is selected with a front panel toggle switch. A single shaft modular pot located at the top of the 1626 module controls the volume. Also, located on the lower front is a quarter inch phono jack for monitoring with headphones. The speakers are connected to the 1018 screw terminals blocks. On the rear cell, a balanced output of the frame audio buss is also available. Further, the 1626 offers a low power mode that allows limiting the total speaker output to 5 watts. This could be used to protect the speakers, to conserve power usage from the frame or limit heat build-up. The external balanced or unbalanced source can be connected via 1018 rear cell through screw type terminal blocks. The internal source can be pulled from the audio bus inside the DIGIFLEx 1000 frame. The incoming signal level (both channels) can be monitored with the front panel LED level meter. All Link products carry a ten-year warranty including parts and labor.
