Link Electronics DigiFlex 1171 1x8 SDI Distribution Amplifier, 1071 Rear Cell

The Link 1170/1171 DigiFlex serial digital (SDI) video distribution amplifier restores the incoming signal to its proper amplitude. The signal is reshaped with automatic equalization, re-sliced and DC restored. Eight outputs are provided on a removable rear cell. A module fault LED on the front edge of the module indicates that the input signal level is below a pre-set threshold. This threshold may be adjusted to suit the users needs. A second module fault LED is located on the rear cell and is therefore visible from the back of the equipment rack. A rear I/O module must be selected for the specific front signal module. The signal module and rear I/O module, with the flexibility of the frame, place virtually no limits on the versatility of the DigiFlex 1000 system. The 1170 and 1171 accepts composite 143 Mb/s and 177Mb/s, component 270Mb/s and 16:9 aspect ratio 360Mb/s standards. The module is transparent to the incoming signal data rate. The 1171 output level can be user adjusted between 600mV and 1100 mV. The 1170 has a fixed output level of 800mV. The 1000 series DigiFlex modules are compact designs that allow eleven modules to mount in the 1000 frame or ten modules with a redundant power supply. Any DigiFlex series modules will operate in the 1000 frame in any configuration, digital or analog, video or audio. The 1000 system is well suited for small or large systems. The product is backed by a ten-year warranty including parts and labor.
