Link Electronics 816-OP/D SDI AES Audio Switch Matrix for AVS-816

The AVS-816 has eight options to configure the unit to be Analog, SD/SDI or HD/SDI for Video and Audio. The audio can be configured for AES or Analog. The 816-OP/D is the AES/EBU audio plug-in board. The AVS-816 chassis and the 816-OP/D board make up an AES/EBU audio only switcher. NOTICE, you must choose the rear connector option for BNC or Balanced. Options 816-OP/F is the BNC unbalanced input. Option 816-OP/E is the balanced 3-Pin connector.You must select the AES audio matrix and video matrix to make up the desired switcher format. You have the choice of analog or AES audio. In the case of AES audio, you have the option of BNC unbalanced or Plug-in 3-pin Weco balanced connectors. You can choose the 816-OP/D, AES plus the connector board for an audio switcher only. The AES matrix has one AES output and one analog output for monitoring. Software is supplied with all AVS series to control up to 32 switchers from a single computer.
