Lichee Pi NanoFW(16M) Cross-Border Core Board ARM 926EJS 32MB DDR with WIFI Module + TF WIFI Adapter Development Board Mini PC

Specifcation sheet (click for more info.) Description: Using F1C100s as the main chip of lichee pi Nano, Arm9 architecture, 16KB D-Cache, 32KB I-Cache, support boot from SPI Flash or TF card, support USB OTG loading update. Hardware parameter CPU: All-in-one F1C100s, ARM 926EJS, up to 900MHz RAM: Integrated 32MB DDR Storage: Reserved SOP8 SPI Flash pad (16M Flash) Onboard TF card holder, can be started by TF. The tf wifi module can be added. Display: Universal 40P RGB LCD FPC Block Can be directly inserted into the common 40P 4.3/5/7 inch screen (onboard backlight driver) through the adapter board can be inserted 50P 7/9 inch screen Support 272x480, 480x800, 1024x600 and other resolutions On-board resistive touch screen chip supporting resistive screen Support 720P video output Support video stream decoding such as H.264 / MPEG Communication Interface: SDIO, can be used with the supporting SDIO WiFi module SPI x2 TWI x3 UART x3 OTG USB x1 TV out x 1, TV in x 2 Other interface: PWM x2 LRADC x1 Speakerx2 + Mic x1 Electrical characteristics: Micro USB 5V power supply; 2.54mm pin 3.3V~5V power supply; 1.27mm stamp hole power supply Output 3.3V, selectable input RTC voltage 900MHz linux no-load operating current 54mA, with screen operating current ~250mA Storage temperature -40~125C, operating temperature -20~70C Support: CSI Camera Full HD Video Engine(H.264,H.263,JPEG/MJPEG,etc.) RGB LCD Interface CVBS Input/Output Audio Codec I2S/PCM SD/eMMc Any quesion, can join this telegram group for communication. Package Included: 1x Lichee pi Nano board 1x WIFI module 1x TF WIFI adapter 1x Adapter
