Lichee Nano Motherboard F1c100s Development Board Linux Programming Learning

Electrical characteristics:- Input 5V through the micro USB port, input 3.3 to 5V through the pin- Output - 3.3V, optional input RTC voltage- Power consumption - 54mA (idle) when using Linux, 250mA with display- Storage temperature: -40~125°C; Operation: -20 to 70°C- Sipeed Lichee Nano with Flash Linux Development Dev. Board 16M Flash VersionIOT Internet of Things- Lichee Nano is a SD card sized Linux development board powered by the Allwinner F1C100s ARM9 processor. - Lichee Nano 22Процессор-Allwinner F1C100s, ARM 926EJS processor, up to 900MHzMemory and storage- 32MB DDR integrated into SoC, 16MB SPI Flash- Onboard TF slot, can be booted from TF card,Отображать- 40pin RGB LCD FPC connector, supports 272×480, 480×800, 1024×600 and other resolution resistive displays (and capacitive displays through the adapter board).- Support 720P video output, support video stream decoding such as H.264 / MPEGКоммуникационный интерфейс- SDIO for WiFi module- SPI x2, TWI x3, UART x3- OTG USB x1, TV outputДругой интерфейс- PWM x2, LRADC x1- Headphone output x2, Mic x1 Software and development environment: Support for 3.10 BSP linuxSupport 4.19 main line linuxSupport xboot bare metal development environmentSupport RT-ThreadTarget application scenario: IoT applications use more complex communication interfaces and protocolsThe application of human-computer interaction interface requires more beautiful and complex logicApplication scenarios that require more operations (as opposed to regular MC
