Lian-Li UNI FAN SL V2 ARGB PWM Case Fan White 140mm
• Slide In Daisy-Chain Style• Improved Performance• Sophisticate Lighting Effects• Cableless with Controller• Start / Stop Fan• L-Connect 3 Software
Upgraded Modularity
UNI FAN SL V2 revised its interlocking style to connect up to 6 fans in two clusters to a single controller port, making cable management simpler.
Extension Cable
With the new 18 cm extension cable, the ability to bridge two clusters of fans to create a 3+3 daisy-chained cluster is offered. These 6 fans can then be connected to a single port on the SL V2 UNI HUB controller. The new daisy-chaining solution reduces the number of cables needing to be managed at the back of the case and enables new lighting effects which can be continuous between the two bridged clusters.
Plug-in Power Cable Module
The cable module is designed to plug in and sit flush with the fan frame, which doesn't require extra space for the module and reduces clearance issues with radiator fittings.
Removable Key
The interlocking keys on each fan are removable to improve compatibility with radiator fittings.
Improved PerformanceThanks to a slight increase to a 28mm thick frame (120mm), 25mm thick frame (140mm) the SL120 V2 features a airflow optimization compared to the SL120 V1, SL140 V1, which creates a great balance of airflow and static pressure.
• Airflow 64.5 CFM
• Static Pressure 2.59 mm H2O
• Noise 29.2 dBA• Speed 0, 250-2000 RPM
Thicker Impeller: Increased thickness to 28mm for better efficiency
Magnetic Frame: To provide extra support for fan blades
Magnetic Rubber Ring: To ensure extreme stabilityFluid Dynamic Bearing (FDB): To effectively reduce the internal friction for improved durabilityCirclip: To secure the fan blades in placeStator: To provide a rotating magnetic field that generates momentum
Extra Magnetic Force: To support the fan blades and reduce vibration levels, thus ensuring a low noise level while in operation
Rubber Pads: To reduce vibrations and ensure extremely low noise levels
More Sleek Lighting Design - Detail OrientedThe cut edge of the rubber pads is designed to create a smoother curve along the light diffuser.Continuous LED ChannelThe light gap between the two fans when interlocked together has been reduced from 5.6mm to 3mm, sketching out the elegant lighting effects.
Dazzling at All Angles
The center of the rear fan has been decorated with an aluminum medallion for an aesthetic look in any orientation.
More Lighting Effect Choices
New lighting effects have been developed for the updated version of the SL fans, offering more lighting options: Render, Tunnel, Voice, and Groove.
Merging Lighting Effects
A merge function is available to allow lighting effects to flow not only across a single cluster but across the whole system.Simple Connection With Controller
The all-new cable module and UNI HUB controller simplifies cable management and provides efficient power to the fans.
16 Fans in One Go
The included controller in the triple pack can support up to 16 fans and 2 SM-type connected devices.
Only One Cable
Combining both the power cable and the lighting cable into a single one, the cable module uses a 7-pin connector to connect to the controller, efficiently reducing the number of cables cluttering the PC build.
Direct To Motherboard
The single pack includes a cable module that features a 4-Pin PWM and a 3-PIN SM-type ARGB cable (3P to 3P 5V ARGB cable is included) to connect directly to the motherboard.
Indented Screw HolesImplementing Indented screw holes to fit standard 25mm screws for mounting with the radiator. When using gasket or mounting the fan directly to the case with the radiator underneath, suggesting use #6-32 X 1-1/2 inch screws.
L-Connect 3 Software To Control SL-V2 Fans
Control and preview with precision the lighting effect of the SL-V2 fans with the new L-Connect interface.Note: Each port can support up to 6 fans while the maximum number of fans supported by the controller is 16.
