Leke Balanced BMS 10S 36V 20A Li-ion Battery Charge Board Equalizer PCB Protection

Description: Balanced BMS 10S 36V 20A 30A Li-ion Battery Charge Board Equalizer PCB Short Circuit Protection Common Port For Escooter Specifications: 20A Version Type: ternary lithium/10 string/36V Connection method: negative pole-same port Discharge: Over-discharge protection voltage: 2.7V±0.03V Over-discharge recovery voltage: 3.0V±0.03V Over-discharge protection delay time: 1000ms Continuous discharge current: 20A Overcurrent protection current: 80A±5A Overcurrent protection delay: 1000ms Short circuit protection delay: 300us Over current short circuit recovery conditions: charge recovery or disconnect the load Recharge: Overcharge protection voltage: 4.25±0.015V Overcharge recovery voltage: 4.15±0.015V Overcharge protection delay time: 1000ms Continuous charging current: 20A Charging protection current: 40A±2.5A Charge equalization voltage: 4.2V±0.025V Charge equalization current: 43mA 0V start charging: Allowed (support 1.2V minimum) Charger voltage: 10*4.3V (recommended) Working power consumption: ≤40uA Main circuit conduction internal resistance: ≤10mΩ Temperature range: -40 to +80°C Disconnection protection: Yes Size: 69*50*9.5MM Package Included: 1*Charge Board Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data.
