Lectrosonics Quadpack Power & Audio Interface for SRa Series Receivers

Make your field recording sessions more efficient and organized with the Lectrosonics Quadpack Power & Audio Interface for SRa Series Compact Receivers. This device is specifically designed for portable applications, offering a streamlined solution for mounting and interconnecting two SRa receivers, thereby enabling the management of 4 audio channels. The Quadpack's lightweight yet robust construction makes it an ideal addition to your bag systems, providing ample space for your mixer, recorder, and transmitters for seamless audio feed to cameras. It ensures all your connections are neatly routed and easily accessible, with one set of audio outputs dedicated to feeding a recorder and another set for the mixer. Powering the Quadpack is made convenient with an external DC source through one or both of the connectors. It features smart circuitry that draws power from the jack with the higher voltage, allowing for a backup power supply to prevent any interruptions if power is cut from one of the jacks. The Quadpack is equipped with interchangeable side panels, housing LZR and Hirose 4-pin power connectors, 4 balanced TA3 outputs, and 4 balanced XLR connectors. These panels are secured with four screws, two on the top and two on the bottom, enabling you to easily switch panels to their opposite sides if required. To avoid any damage, it's recommended to use a connector, such as Hirose, Power, or XLR, on one of the lower connectors to remove the panel. The pin connectors for the side panels are conveniently located on the lower end of the panel. In summary, the Lectrosonics Quadpack Power & Audio Interface for SRa Series Compact Receivers offers a comprehensive solution for managing your audio channels in the field, ensuring reliability, efficiency, and ease of use.
