Leader ZEN-W Series LV7600W 1RU 4K/12G-SDI/HDR/IP/JPEG-XS Rasterizer with WebRTC

The LV7600W is a 'True-Hybrid' rasterizer compatible with 4K/HD/SD-SDI signals and UHDTV/HD/SD IP signals. The LV7600W offers the same functions as the LV5600W in a 1RU, full-rack enclosure and supports a variety of SDI signals up to 12G-SDI as well as video over IP. The waveform, vector, picture, audio, and eye pattern displays enable simple yet comprehensive measurements and quality control of the widest range of audio and video formats. The status display allows you to assess errors and system stability with both event logs and long-term charts.For audio, these instruments support digitally embedded audio in SDI or IP streams as well as discreet digital and analog audio connections. Multi-channel audio levels, Lissajous, status, and loudness displays are available.Finally, a fully customizable screen layout allows the LV7600W to easily solve complex measurement and monitoring tasks. Designed with the future in mind, the LV7600W addresses your current and evolving video and audio testing needs.WebRTC EnabledThe LV7600W supports the Web Real-Time Communication interface. WebRTC allows secure remote control and monitoring from a web-connected desktop or laptop computer.Supports 'True-Hybrid' SDI/IP WorkflowsThe LV7600W can monitor SDI signals up to 12GfSDI as well as IP (video over IP). Audio support can include SDI embedded Audio, Audio multiplexed to IP, external input AES/EBU, and analog Audio. In addition, the LV5600W or LV7600W can be configured to simultaneously monitor SDI and IP feeds - 'True Hybrid' monitoring for complex networks.4x IP MultistreamPacket Jitter, Path Delay, Timing Comparison and Pack Buffer can all be viewed simultaneously.Customizable LayoutVarious items such as video signal waveforms, vector waveforms, and pictures of input signals can be laid out in any position with your favorite size.HDR MonitoringIn addition to HLG and PQ provided by ITU-R BT.2100, the level monitoring of the HDR signal corresponding to S-log3 and the level management at the assumed luminance (Nits) in a display considering OOTF are possible.The video signal waveform displays HDR scale along with the IRE scale. In the cine zone display, the luminance distribution of the HDR area can be easily confirmed by displaying the SDR area in monochrome, and the HDR with a color according to the brightness.TALLYSerial communication RS-422/485 terminals enable to display camera ID, and tally. Fast switching of tally display by remote terminal is also possible.Video Noise Meter FunctionThis function measures the noise in the luminance and RGB signals of SDI and IP signals input to the LV7600W.It is useful for camera noise measurement.Dolby-EDecoding display of Dolby E, Dolby Digital, Dolby Digital Plus becomes possible by adding LV7600-SER 04 to LV7600-SER 03 option.Focus AssistThis is a focus detection function realizing a new algorithm based on nonlinear super resolution technology. The focus details can be detected with high sensitivity even with low-contrast images, which were conventionally difficult to detect. In addition, sensitivity can be selected from 5 levels according to the video scene.3D-LUT FunctionBy loading a 3D-LUT cube file, the 3D-LUT can be converted in real time to support various measurements and conversion outputs.(SER23 option is required.)Supports Full Range SDRSupports waveform display, vectorscope, CIE chart, histogram, CineLite, CineZone, and full range of DPX and TIFF file capture.False Color Display SupportFalse color display can be added to pictures, making it easy to determine highlights, human skin tones, 18% gray, blacks, etc.
