Leader 8.4" TFT LCD Multi SDI/HDMI Monitor, 720p Resolution

The Leader 8.4" TFT LCD Multi SDI/HDMI Monitor is a portable waveform monitor that supports SDI and HDMI signals. It can display simultaneously up to four HD-SDI signals and it supports HDMI packing, side-by-side and top-and-bottom formats. A battery option is also available. Features Tailored to 3D Filming The LV5382 can handle 3D content with its support for HD-SDI 2-channel simultaneous display and HDMI frame-packing, side-by-side and top-and-bottom formats. The LV5382 has a number of features that are useful for evaluating 3D content. The anaglyph display enables easy expression of stereoscopic vision. The variable grid display is for horizon and parallax checking. The vertical and horizontal reversal feature is necessary when using a mirror rig. SDI and HDMI I/O Connectors and the SDI to HDMI Conversion Feature The LV5382 has two SDI input connectors, two reclocked SDI signal output connectors, an HDMI input connector and an HDMI output connector. The HDMI output connector can actively transmit an HDMI input signal or output an HDMI signal that has been converted from an SDI signal. High-Quality TFT LCD The TFT display (XGA with a resolution of 1024 x 768 pixels), which has high color reproducibility, gives the display improved quality and enables you to use the LV 5382 as a picture monitor. Rich Assortment of Display Features Not only does the LV5382 have essential displays for video signal quality monitoring, such as a video signal waveform display and a vector display, it also has a rich assortment of other display features, such as a picture display, audio level meter display, 5-bar display, transmission error detection and gamut error detection. It can also be used for 2D filming in the same manner as previous models. Rich Assortment of Waveform Features The LV5382 uses fully digital waveform display processing to achieve high precision and quality. The video signal waveform display has gain, sweep and cursor measurement features, along with RGB and pseudo-composite display features. In addition to video signal waveforms, the LV 5382 can also display vectors, the Lissajous curves of embedded audio and level meters. Versatile Picture Display The LV 5382 uses fully digital picture display processing to achieve high precision and versatility. The display has a number of adjustment features such as color temperature selection, brightness adjustment, contrast adjustment, gain adjustment and bias adjustment. It also has monochrome, chroma up, gamut error and safety marker display features. Versatile Display Layouts The LV5382 has a 1-screen display in which the picture, video signal waveform, vector or audio meter display can be displayed in a single screen, a multi-screen display in which these displays can be combined and a 2-channel simultaneous display in which two SDI signals can be displayed simultaneously. Also, users can register up to four user layouts that specify preferred display locations and sizes. Standard-Equipped CINELITE II The CINELITE feature makes it easy to manage the levels of specific points on the picture display. This is useful for adjusting the gain of multiple cameras through the use of the same reference point. The CINEZONE feature makes it possible to check the luminance distribution of the whole picture display at a glance. S-Log Exposure Function Capabilities (Option) In order to manage the challenges of the S-Log (exposure) feature in certain cameras, Leader has created an option for it. You can now see clearly the details that are included in a shot by turning on the Low Key function (for over-exposed images) or High Key function (for under-exposed images). In addition, now the image can be zoomed in on the instrument without affecting the focusing captured from the camera. Screen Capture Feature The display can be captured and stored as still-image data. The captured data can be displayed on the LV 5382. Additionally, it can be saved as bitmap files to USB memory, which makes it possible to view the data on a PC. External Sync Input The LV5382 can receive a tri-level sync signal or an NTSC or PAL black burst signal as its external sync signal and then display video signal waveforms with this sync signal as its reference. Preset Feature Up to 30 sets of panel settings can be registered as presets and loaded easily at a later time. Registration of settings that are used repeatedly can help you work more efficiently. In addition, the LV5382 has a display mode preset feature that can be used to register the settings for each display-the video signal waveform display, vector display and picture display. This makes it possible to use the displays according to different usage conditions. Key LEDs All the panel keys have LEDs. This makes it easy to find the keys even in dark environments. Last Memory Feature The LV5382 always keeps a backup of the current settings. When the LV 5382 is restarted, it can be used with the same settings that were in use before it was turned off. ID Display IDs can be assigned to input signals. IDs are entered from the LV5382 panel. Stereo Headphone Output The LV5382 can deliver the embedded audio of an SDI signal or HDMI signal in stereo through the headphone output jacks.
