LZSAA-2 V2 50KHz-3GHz Vector Network Analyzer 2.8 Inch Digital Nano VNA Tester MF HF VHF UHF USB Logic Antenna Analyzer

Description S a a 2 portable vector network analyzer up to 3GHz designed by owocomm We manufacture in strict accordance with the document of owocomm using 0 5ppm TCXO to ensure the frequency accuracy of high frequency measurement The complete metal shell can fully protect the internal precision circuit and fully consider the protection of external interface The customized high performance ss405 cable provides good amplitude and phase stability and the high performance calibration kit ensures that the calibration SWR is less than 1 03 at 3GHz Product performance Frequency range 50KHz 3GHzFrequency error 2ppmFrequency temperature 0 5ppmSystem dynamic range calibration 70dB up to 1 5GHz 60dB up to 3GHz S11 noise floor calibration 50dB up to 1 5GHz 40dB up to 3GHz Scanning speed 100 points SDisplay saa2 2 8 320 x 240RF port saa2 SMA saa2n n if you need to measure anti pin SMA equipment such as wifi antenna please use SMA to rpsma connector USB interface microusbPower supply USB maximum charging current 1aBattery saa2 2000mAh lithium ion saa2n 3000mAh lithium ionBattery connector jst xh 2 54mmMax scan point on device screen 201Maximum scan point USB 1024Return loss of port 2 1 5GHz 20dB typPort 2 return loss 3GHz 13dB minVna qt software compatible system Linux windows 7 OS plannedOuter package size 140 100 40MMSmall package weight 480 GPackage includes 1 x S a a 2 host with 2000mAh battery 1 x USB cable2 x 30cm
