LVDS to eDP Universal Driver Board LVDS to EDP Adapter Board eDP LCD Screen Signal Adapter Board DP_N173HGE_V6.1

This item need to used with a driver board like T SK105A 03Feature Support 1 2 4 lane EDP 1366 768 1920 1080EDP signal output I PEX 20455 30PINLVDS input DuPont 30P 2 0 pitchNo short circuit any pins the default resolution is 1920 1080 1920 1200With short circuit R16 resistor is 1366 768 1280 800 1440 900 1680 1050 1600 900R15 short circuit is connected to 1 lane EDP LCD screenR16 short circuit is connected to 4 lane EDP LCD screenR15 R16 open circuit is connected to 2 lane EDP LCD screenNote The jumper on the LVDS driver board must jump to the 3 3V position to avoid burning the EDP adapter boardIf the backlight is not bright you can short the ADJ ENA pinPartially applicable EDP models incomplete list 1 B116XAN02 0 1LANE2 B113HAN03 0 HW 1A3 B140RW01 V24 B140XTN02 4 0A 1LANE5 B140XW01 V46 B156HAN01 1 0A 2LANE7 B173RTN01 1LANE8 CLAA133UA03 CW9 HN133WU1 10010 HV121WX5 12111 LP156WF1 TPB112 LP156WF4 SPB113 LTN141AT05 10A14 N116HSE EA115 N116HSG WJ116 N133HSE EA117 N140B6 D1118 VV13F009G10 Package includes 1 x Adapter Board1 x Cable
