LT1083 Adjustable Regulated Power Supply Module Parts DIY Kit

Features:LT1083 adjustable regulated power supply is based on a low three steadied LT1083 chip adjustable regulated power supply.Circuit 10 has four main a10 rectifier diode rectifier circuit, comprising 50 v / 4700 uf capacity,TL1083, adjustable voltage regulator circuit, comprising W502 potentiometer, the output circuit 7 and a recovery car fusethe four 10 a10 rectifier diode, AC power conversion to DC power supply, through 50 v / 4700 uf capacitor filterW502 adjusting potentiometer, can adjust the output voltage LT1083 7 a recovery car fuse, can prevent the output of the circuit is too large, with output protection functionTechnical specifications:Board size: 74mm x 46mmDC Input: 2.5 V-38 VInput AC: 2.5 V-27 VDC output: 2.5 V-35 Vmaximum current: 7Ainlet and outlet pressure differential minimum: 2.5 voltsPackage Included:1 x DIY Module
