LS055R1SX03 5.5 inch 2k LCD Module 2560*1440 LCD Screen Display with HDMI to MIPI Controller Board For Wanhao Duplicator 7 SLA 3D Printer / VR

Specifications: Module Dimensions 70.94(W)mm*128.26(H)mm*1.35(t)mm(Excluding I/F -FPC and electronic components) Active Area Dimensions 68.04(W)mm*120.96(H)mm(5.46") Pixel Pitch 0.04725(W)mm*0.04725(H)mm(538ppi) Resolution 1440*2560 Color Pixel Arrangement RGB Vertical Stripe Display Mode Transmissive Type,Normally Black Mode,In-Plane Switching Mode Number of Colors 16,777,216 Colors Backlight Light Emitting Diode(LED),14LEDs are 2 parallel,7 series connection Backlight current:20mA/LED(typ) Power Supply Voltage AVDD=5.5+/-0.1V AVEE=-5.5+/-0.1 V Interface I/O Power supply Note(1) VDDI=1.8=/-0.1V The same voltage as "H" level of a customer's interface signal must be supplied to VVDI LCD Driver IC (Source and Power IC: Renesas SP Driver Inc.) Interface MIPI_DSI Video mode(4-Lan x2-port) Method of Inversion Column Inversion Surface Treatment HC-Polarizer(Hardness:3H) Notes: When you start to use the screen, please take the back light off, here is the video for your reference. Package Included: 1x LS055R1SX03 Screen 1x Driver controller board 1x FCC cable
