LOTO OSCH02F 2 Channel USB PC Virtual Digital Oscilloscope 100MHz Bandwidth 1GSa/s Sampling Rate Logic Analyzer

Please Click Here to Download the English User ManualFeatures Hand held portable 153 L x 93 W x 30 H mm1G 250M Maximum sampling rate 100M bandwidth 2 channels 8 Bit 13 Bit vertical resolution Open source hardware interface to support expansion modules USB 2 0 interface USB powered Comes with PWM output 72 hours long time data logger Optional logic analyzer Signal generator and isolated differential inputsupport module Waveform recording and playback review Support waveform image import as the comparison reference for real time waveform Support Serial bus decoding RS 232 RS 485 422 I²C CAN SPI Supports a variety of current clamps and other physical volume custom probes Support buffer waveform preview and mouse wheel operations Historical change trend statistics and analysis functions Pass Fail detection Support spectrum analysis and frequency response curve mapping Support FIR Digital Filtering function Application General purpose and precision testing Embedded in industrial testing equipment for use Embedded electronics courses for the educational market Ripple and noise measurements for power supply characterization Multi sensor systems and Serial bus decoding Car inspection and maintenance Current Voltage recording and analysis System for Solar Power Supply and Lighting System Diagnosis device for field engineers Basic equipment for DIY makers to develop their own modules Specifications Connector type 2 channels with BNC
