LM2596S-ADJ Module DC-DC Buck Regulator Power Supply Module

Features This is a flexible and easy to use LM2596 DC DC step down module which can flexibly set the output voltage through a 6 position DIP switch It also has an indicator light display The input and output are all 4 position binding posts which can be connected to different places as needed It is very convenient to use multiple strands of wire on one terminal 1 Other adjustable ones are mostly adjusted by a 3296 potentiometer The adjustment needs not only a small screwdriver but also the output voltage must be monitored with a voltmeter to adjust to the appropriate value The use is very inconvenient and this module uses The 6 position DIP switch performs a coarse adjustment in 0 5V steps and the 3296 trimmer potentiometer fine tuning allows you to quickly and easily preset to any 1 5V 33V voltage Parameters Input voltage 5V 36VOutput voltage 1 5V 33V 0 5V step through an adjustable resistor to fine tuneOutput Current 3A 2A ratedModule size 61 40 mmPackage Included 1 x DC DC step down moduleNote 1 We have already adjusted the trimming potentiometer The user can directly dial the DIP switch to set in 0 5V steps If the user adjusts the trimming resistance by himself if 0 5V step setting is required the trimming potentiometer needs to be set again Just adjust it back
