LINK-MI LM-EW30 30m Dual Cat5e/6 HDMI Wall Plate Extender With Infrared Control
Description
Features
Each set includes one transmitter and one receiver.
Following North American wall plate standard.
Modular design.
Use Dual UTP cable（Cat5E/6）to substitute HDMI cable to achieve long distance transmission, the UTP Cable follows the standard of IEEE-568B.
Transmission distance reaches up to 30 meters under the video format of 1080P.
Auto-adjustment of feedback, equalization and amplify.
Signaling rates up to 2.25Gbits in support of 1080P display.
With Infrared control signal passing through function.
Supply 3D video format.
CEC Pass-Through.
Connecting and Operating
Connect the HDMI input source (such as HD-DVD / PS3 / STB etc) into TX.
Connect the two CAT-5E or CAT6 cables to both the outputs of TX and inputs of RX. Please pay attention to the right connection of the two cables, CAT5e/6-1＞CAT5e/6-1 (The cables must follow the standard of EIA/TIA 568B).
Connect the HDMI output (such as HD-LCD / HD-DLP) into RX.
Connect the IR TX UNIT into TX; Connect the IR RX UNIT into the RX.
Transmission distance reaches up to 30 meters under the video format of 1080P.
Specifications
Brand LINK-MI
Model No. LM-EW30
Material PE Plastic
Color White
Interface HDMI
Application Extend HDMI Signal up to 30m over single UTP cable
Operating Temperature Range -5 to +35℃ ( +23 to +95℉ )
Operating Humidity Range 5 to 90%RH ( No Condensation )
Input Video Signal 0.5-1.0 Volts P-P
Input DDC Signal 5 Volts P-P ( TTL )
Video Format DTV/HDTV: 480i/576i/480p/576p/720p/1080i/1080p
Video Output HDMI
Audio Format DTS-HD Master Audio, Dolby True-HD etc.
Transmission Distance 1080p 8-bit 30m (Max. ); 1080p 12 bit 25m ( Max. ) Over Cat5e/6/24AWG/Solid ( Recommend to use 23AWG Cat6 Cable )
Wavelength 940nm
Frequency 38KHz
Power Consumption 3 Watts ( Max. )
Dimension ( L x W x H ) 115 x 70 x 35mm
Packing Contents
1 x HDMI Wall Plate Extender Transmitter & Receiver
1 x IR TX Unit ( IR Emitter Cable )
1 x IR RX Unit ( IR Receiver Cable )
1 x Operating Instructions
