LILYGO® TTGO T-Camera Plus ESP32-DOWDQ6 8MB SPRAM OV2640 Camera Module 1.3 Inch Display With WiFi bluetooth Board

More details: https://github.com/Xinyuan-LilyGo/esp32-camera-screen Hardware Specifications Chipset ESPRESSIF-ESP32-DOWDQ6 240MHz Xtensa dual-core 32-bit LX6 microprocessor FLASH QSPI 4M flash / 8M SRAM SRAM 520 kB SRAM + 8MBytes External SPRAM KEY Reset Dispaly IPS Panel ST7789/1.3 Inch Power indicator lamp Red USB to TTL CP2104 Camera OV2640 2Megapixel on-board clock 40MHz crystal oscillator Working voltage 2.3V-3.6V Working current about 160mA Working temperature range -40 to +85 Size 69.13*28.41*8.45mm Mic MSM261S4030H0 SDCard Integrated external SD card slot Sensor BME280/humidity/pressure/temperature Power management chip IP5306 Power Supply USB 5V/1A Charging current 1A Battery 3.7V lithium battery WIFI Description Standard FCC/CE/TELEC/KCC/SRRC/NCC Protocol 802.11 b/g/n/e/i (802.11n, speed up to150Mbps)A-MPDU and A-MSDU polymerization, support 0.4S Protection interval frequency range 2.4GHz~2.5GHz(2400M~2483.5M) Transmit Power 22dBm communication distance 300m bluetooth Description Protocol Meet bluetooth v4.2BR/EDR and BLE standard Radio frequency With -98dBm sensitivity NZIF receiver Class-1,Class-2&Class-3 emitter AFH Audio frequency CVSD&SBC audio frequency Software specification Description Wifi Mode Station/SoftAP/SoftAP+Station/P2P Security mechanism WPA/WPA2/WPA2-Enterprise/WPS Encryption Type AES/RSA/ECC/SHA Firmware upgrade UART download/OTA (Through network/host to download and write firmware) Software Development Support cloud server development /SDK for user firmware development Networking protocol IPv4, IPv6, SSL, TCP/UDP/HTTP/FTP/MQTT User Configuration AT + Instruction set, cloud server, android/iOSapp OS FreeRTOS TTGO Camera VS TTGO Camera Plus: Function TTGO T-Camera (Product ID: 1418433) TTGO T-Camera Plus (This item) MIC not supported supported SDCard not supported supported BME280 not supported not supported Charging supported supported I2C supported supported Screen OLED SSD1306/0.96 IPS Panel ST7789/1.3 Camera OV2640 OV2640 PIR supported not supported User button supported not supported Core ESP32-WROVER-B ESP32-DOWDQ6 PSRAM 8MBytes 8MBytes FLASH 4MBytes 4MBytes UART CP2104 CP2104 Package includes: 1 x TTGO T-Camera plus (Normal/Fish-eye Lens optional)
