LHCER Parallel Gripper Cylinder Gripper Pneumatic Cylinder Double Action Parallel Grippers Cylinders MHZ2‑16D M5‑0.8 Finger Gripper Cylinder

Feature: 1. Hard Oxidized Cylinder Block: The cylinder is a hard oxidized cylinder block which increases the surface hardness is not easy to deform and is compression resistant and durable. 2. High Strength Accuracy Guide Rail: The cylinder adopts high strength accuracy guide rail which is not easy to loosen the steel ball does not fall the work is and the accuracy is high. 3. Circlip Super Sealing: The cylinder is equipped with a circlip super sealing and self lubricating seals to prevent gas blow by in the left and right chambers of the cylinder with small errors and high working efficiency. 4. Can Bear Side Load: This finger cylinder can bear larger side load and moment suitable accuracy assembly. 5. Aluminum Alloy: This is a 0.7Mpa cylinder made of high quality aluminum alloy strong and durable not easy to damage. Specification: Item Type: Gripper Pneumatic Cylinder Material: Aluminum Alloy Model: MHZ2-16D Bore Diameter: Approx. 16mm / 0.63in Working Pressure: 0.1-0.7MPa Airs Inlet Thread: M5-0.8 Claw Distance When Closed: Approx. 14.9mm / 0.59in (There is an error of ±0.3mm in manual measurement) Claw Distance When Opening: Approx. 20.9mm / 0.82in (There is an error of ±0.3mm in manual measurement) Stroke: Approx. 6mm / 0.24in Outer Diameter Clamping Force: 34N Inner Diameter Clamping Force: 45N Environment and Fluid Temperature: -10~60℃ Repeatability: Approx. ±0.01mm / 0.0004in Maximum Frequency: 180c.p.m Give Oil: Not Needed Liquid: Airs Action Type: Double Action Package List: 1 x Finger Cylinder Note: 1. In strong magnetic environment use a switch cylinder with strong magnetic field resistance; 2. When there is a lot of dust water droplets or oil droplets a telescopic protective sleeve should be used on the cylinder rod side; 3. In environment with iron powder and iron filings nearby if is not protected the magnet will attract the iron powder and iron filings to gather around which will weaken the magnetic force in the cylinder which may cause the magnetic switch to fail; 4. In the high and low temperature environment the cylinder sealing ring should be high temperature resistant or low temperature resistant sealing ring. 5. The distance between the cylinder barrels of the two parallel cylinders must be greater than 40mm otherwise the magnetic switches of the two cylinders will be interfered with each other and cause malfunction.
