LCR-T4 ESR Meter Transistor Tester Diode Triode Capacitance SCR Inductance+Hous

Features: - Brand new and high quality - Made of high quality materials durable -128 * 64 large backlight LCD display only 2mA in standby. -Using a 9V battery (not included) -Inductor capacitor diode dual diode mos transistor SCR voltage regulator LED tube ESR -Resistance adjustable potentiometer -Resistance: 0.1 ohm resolution maximum 50M ohms -Capacitor: 25pf-100000 uf -Inductor: 0.01mh-20H -Automatic detection of NPN and PNP transistors n-channel and p-channel MOSFETs diodes (including dual diodes) thyristors transistors resistors capacitors and other components -Automatically test component pins and display them on the LCD -It is possible to detect the amplification factor and base of transistors and MOSFET protection diodes to determine the forward bias voltage of the emitter transistor -Measure the gate and gate capacitance of the MOSFET threshold voltage -Use 12864 LCD display with green backlight characteristic: 1: One button operation automatic shutdown. 2: Only 20 closing current. 3: Automatic detection of NPN PNP bipolar transistors N-channel and P-channel MOS FETs JFET diode two diodes thyristor small power unidirectional and bidirectional thyristors. 4: Automatically identify component pin arrangement. 5. Measure the current amplification coefficient and the base emitter threshold voltage of the bipolar transistor. 6: Identify Darlington transistors by base emitter threshold voltage and high current amplification factor. 7: It can detect bipolar transistors and MOS transistor protection diodes. 8: Measure the gate MOS FET threshold voltage and gate capacitance. 9: It is possible to measure two resistors simultaneously and display the resistor symbol. Displayed on the right with a decimal value of 4. The resistance symbols on both sides display the pin number. So you can measure the potentiometer. If the potentiometer wiper is not moved to the limit position we can distinguish between the middle and both ends of the needle. 10: The resistance measurement resolution is 0.1 ohms which can measure 50M ohms. 11: Capacitance can be measured. Capacitance can be measured from 30 pF to 100 with a resolution of 1 pF. At 12:2uF more capacitors can simultaneously measure the equivalent series resistance ESR value. Both can be displayed as decimal values with a resolution of 0.01 ohms. 13: The two diodes can be displayed in the correct order and symbol and the diode forward voltage can be given. 14: The LED was detected as having a high diode forward voltage. The combination of LEDs is identified as two diodes. The Zener diode can be identified when the reverse breakdown voltage is less than 4.5 V. 16: The reverse capacitance of a single diode can be measured. If a bipolar transistor is connected to the base and collector or emitter of a pin it can measure the reverse capacitance of the collector or emitter junction. . 18: Can be obtained through a single measurement rectifier bridge connection. The package includes: 1 * LCR-T4 battery button+housing or 1 * LCR-T4 battery box+housing Notes: 1. Due to various factors such as display brightness and light brightness the actual color of the product may be slightly different from the website picture. 2. Please allow a slight deviation between the data and the manual measurement.
