LCR Handheld Impedance Tester Digital Bridge Measuring Resistance Capacitance Inductance Adjustable 50 to 100KHz

LCR Handheld Impedance Tester Digital Bridge Measuring Resistance Capacitance Inductance Adjustable 50 to 100KHz
sku: 1743427
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
9,412.00 руб.
Shipping from: China
   Description
Features:The test frequency range is wide, the frequency range: 50Hz~100KHz. The frequency point can be set.Small size, light weight, easy to carry.Built-in battery, using 2000mAh polymer lithium battery, continuous working time exceeds 4 hours.The resolution is high, and the measurement result is 6 significant digits.Comes with calibration function, accurate measurement.Serial and parallel mode, level and internal resistance are optional.Strong resistance to power frequency interference, prompting the degree of interference.Automatic gear shift without manual intervention.Specifications:Main material: metalColor: blackWorking frequency: 50Hz~100KHzStep: 50Hz (10Hz)~10KHzDisplay: 2.4 inch TFT resolution 320*240 (QVGA)Battery: 1 * lithium battery, 2000mAh (included)Power consumption: 1WCharging current: 400mACharging interface: USB (only as a charging interface)Automatic shut-down: always open, close immediately, 5 minutes to 60 minutes (optional)Measurement parameters: Rs/Xs/Rp/Xp/Cs/Cp/Ls/Lp/Z/D/Q/θ/Vrms/IrmsDC bias: noDisplay resolution: 6 significant digitsMeasurement speed: fast, medium, slowMeasurement accuracy: less than 0.1% within the measurement range, out of range may be greater than 0.1%Connector: BNCDisplay range:Z, R, X: 0.00001mΩ~9999999MΩC: 0.00001pF~9999999FL: 0.00001nH~9999999HD, Q: 0.001~99999θ(degree): -179.9~179.9Vrms: 0.0001mV~999999mVIrms: 0.0001nA~999999mAMeasuring range:Z: 1mΩ~200MΩC: 3fF~3FL: 0.5nH~600kHLevel:mVrms: 1, 002, 003, 004, 005, 000, 000, 00
