LCD LED Panel Tester for TV Laptop Computer Repair Support 7inch-84inch LVDS Screen

LCD screen tester (Sixth Edition) using a new hardware-driven solutions and software programs, the new white-green word panel, screen printing clear and beautiful. Features: 1. easy to use, the sixth edition built-in 55 kinds of LVDS LCD resolution program; 2. through the button to switch the digital display corresponding to the resolution of the value, you can point screen; 3. increase the LCD screen power supply short circuit protection, to prevent the screen line inserted into the dislocation or LCD screen power supply circuit board damage to the driver board, short circuit after the digital display screen display flashing "00" buzzer long ringing, short circuit removed to restore normal Prohibit more than ten minutes long short-circuit); 4. built a variety of standard test chart, test chart function and the role of the following description; 5. test panel comes with operating instructions, use at a glance; 6. with a key automatic baking machine mode, easy maintenance, factory assembled roasted machine; 7. plug in the external VGA cable automatically switches to an external VGA input signal display; 8. almost compatible with 95% of the 7-inch -84 inch LVDS interface LCD / LED LCD screen test; 9. General 12V LCD power supply, the current size of the screen according to the actual needs of the test; 10. to support the development of our eDP interface LCD screen adapter board to support a variety of resolution eDP interface LCD screen test. Specification: Name: LCD LED Panel Tester Support 7''-84'' LVDS Screen Panel Tester voltage selction: 3V/ 5V / 12V 1/2/4 Lamps CCFL inverter Input: 10V-30V Support: 10-22inches Power adapter: Input: 100-240V 50/60HZ Output: 12V 4A Tester size: 130 x 80 x18mm Inverter size: 120 X 40mm Power adapter size: 110 x 50 x 30mm How to use: LCD screen test support standard, high-definition full-resolution LVDS signal, built-in 12 test screen, convenient and practical. Screen switching: can switch cycle test tool built-in 12 kinds of test screen Quality switch: according to the actual display screen effect, switch to the appropriate quality Automatic switching: 12 kinds of test screen automatically cycle display VGA input interface: insert the computer VGA signal, that is displayed on the LCD screen, the tester without any switch VGA output interface: the tester can be 12 kinds of internal test screen signal through the VGA cable to another display, to determine whether the display does not light, the equivalent of a VGA signal source. Package includes: 1 x LCD LED Panel Tester 14 x most common used Lvds screen cables 1 x CCFL backlight lamp inverter 1 x 12V AC power adapter (According to the delivery countries distribute adapter.) Details pictures:
