LCD Display 20A MPPT 12V/24V Solar Panel Battery Regulator Charge Controller

Features: 1 LCD screen display 2 Easy operation interface 3 MPPT+PWM charging mode（Controller Provided MPPT Maximum power point tracking Function charging mode is PWM) 4 Parameter user can reset 5 A key to open and close the load 6 A key to restore the factory settings 7 Battery reverse discharge protection 8 Battery reverse polarity protection 9 Battery under voltage protection 10 Overload short-circuit protection 11 Automatic temperature compensation function 12 Can charge and discharge at the same time Always keep the battery in full status. Specifications: Battery float voltage 13.8V 12V system /27.6V 24V system Battery under voltage) protection 10.6V 12V system /21.2V 24V system Battery (under voltage) recovery voltage 12.6V 12V system /25.2V 24V system Charge mode：MPPT+PWM MODE Operating Temperature ：-10~60°C Storage Temperature：-30~70°C Humidity requirements：≤90% No condensation Temperature compensation：-4mV/Cell/°C Temperature Probe (built components)：NTC 100K thermistats Maximum open circuit voltage of the solar panel 18V-24V 12V system 36V-48V 24V system) Solar panels maximum open circuit voltage (V)：≤48V Package Contents: 1*20A Solar Contorller T20 1* User Manual Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data.
