LA1010 USB Logic Analyzer 100M Max Sample Rate 16 Channel MCU/ARM/FPGA Debug Tool Oscilloscopes
![LA1010 USB Logic Analyzer 100M Max Sample Rate 16 Channel MCU/ARM/FPGA Debug Tool Oscilloscopes](http://imgaz.staticbg.com/images/oaupload/banggood/images/52/03/621a8b76-2f63-4986-a057-fab13a3030de.jpeg)
Eachine1
sku: 1184217
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$74.68
Shipping from: China
Description
Description: LA1010 is a logic analyzer product with high cost performance. It has 16 input channels and the sample rate is up to 100MHz. Along with the PC software KingstVIS, 16 channels of digital signal could be sampled at the same time, and then they could be converted to digital waveform and displayed on the PC screen. The signal could be analyzed with many standard protocols, to get more straightforward communication data. It helps a lot in testing and analyzing digital system(MCU/ARM/FPGA, etc.) developing and debugging several communication programs, or monitoring and recording some digital signals for a long time. Software and user manual: http://www.kingst.org/download/?fl=vis.zip Features: Portable and lightweight Max sampling rate: 100M@3channels, 50M@6channels, 32M@9channels, 16M@16channels Large sampling depth and support compression The built-in PWM generator Compatible USB2.0/3.0 interface Powerful software and easy to use Support online upgrade automatically Specifications: Input channels number: 16 Max sampling rate: 100M Measurement bandwidth: 20M Min pulse width can be captured: 20ns Max sampling depth: 10G/channel Input voltage range: -50V ~ +50V Input impedance: 220K 12pF Adjustable threshold voltage: -4V ~ +4V, step: 0.01V PWM channels number: 2 PWM frequency range: 0.1 ~ 10MHz PWM frequency adjust step: 10ns PWM pulse width adjust step: 10ns PWM output voltage: +3.3V PWM output impedance: 50 Standby current: 100mA Max operating current: 150mA Dimensions: 95mm * 55mm * 23mm Supported OS: Windows XP, Vista, Windows 7/8/10(32/64bit) Supported standard protocols: UART/RS-232/485, I2C, SPI, CAN, DMX512, HDMI CEC, I2S/PCM, JTAG, LIN, Manchester, Modbus, 1-Wire, UNI/O, SDIO, SMBus, USB1.1, PS/2, NEC InfraRed, Parallel, etc... Package included: 1 x LA1010 Host 2 x 9P Flat Cable 1 x 2P Flat Cable 20 x Test Hook 1 x USB Cable 1 x CD
