Kramer Electronics VS-88HDxl 8x8 3G HD-SDI Matrix Switcher

The VS-88HDxl is a high-performance matrix switcher for 3G HD-SDI and HD-SDI dual link video signals. The unit can switch any or all inputs to any or all outputs. Switching is implemented during the vertical interval period according to the SMPTE RP-168 standard, when using synchronized digital video sources. Max. Data Rate 3Gbps. Multi-Standard Operation SDI (SMPTE 259M & SMPTE 344M), HD-SDI (SMPTE 292M), 3G HD-SDI (SMPTE 424M) and dual link HD-SDI (SMPTE 372M). Analog Sync Type Bi-level, tri-level. Take Button Executes multiple switches all at once. Multiple Memory Locations Stores multiple switches as presets (salvos) to be recalled and executed when needed. Vertical Interval Switching Synchronizes either to external reference or the incoming video in compliance with SMPTE RP-168. Flexible Control Options Front panel, RS-232 (K-Router Plus Windows-based software is included), RS-485, Ethernet, IR remote (included). Worldwide Power Supply 100-240V AC. Standard 19" Rack Mount Size 1U. Rack "ears" included.
