Kramer Electronics VP-792 Multi-Format to DVI/HDMI Digital HQV Scaler

The VP-792 is a high-performance scaler for HDMI, DVI, analog VGA and component signals. It up- or down-scales the incoming signal, processes the image with HQV, flexible warping, geometry correction and edge blending and outputs the signal to a DVI/HDMI connector. • Powerful Geometry Correction: For off-axis projection, pin/barrel and image rotation, pan, tilt and zoom • Full Warp Mapping: Easy warp map creation for stacked projector alignment and curved screen multi-projector tiling via an included PC application. • Edge Blending: 4-sided soft edge blend for seamless blending of multiple projectors; basic edge blending for general purpose applications. • Multi-Format Operation: HDMI, DVI, computer graphics and component inputs for signals up 1080p & WUXGA • HDTV Compatible • HDCP Compliant • HDMI Support: Deep color up to 12 bit • Selectable Processing Versus Latency: Best picture and low latency modes; latency as low as 0.25-frame progressive inputs, 1.25-field interlaced inputs. • Selectable I/O Lock Mode: Or frame rate conversion mode • Selectable Aspect Ratio Conversion: Or incoming aspect ratio preserve mode • Flexible Color Calibration Controls: RGB Gains, RGB Cut-Offs/Black Levels, Saturation, Hue, Brightness, Contrast controls, Gamma selection. • Built-in Test Pattern Generator • Non-Volatile Memory: Auto-saves and recalls settings • USB Port: For upgrading firmware • Programmable Customer Logo on Menu • Flexible Control Options: RS-232, TCP/IP API and Web Server, keypad for direct input selection, PC-based Warp Map Generator tool and OSD menu access. HQV Video Processing HQV (Hollywood Quality Video) processing represents the state-of-the-art in video processing technology, with the highest quality de-interlacing (with 3:2 & 2:2 pull down), 4D motion adaptive SD noise reduction and outstanding scaling performance for both standard-definition and high-definition signals. Superior De-interlacing Motion adaptive per pixel video de-interlacing with multi-directional diagonal de-interlace filter reduces HD & SD image flicker and artifacts. Supported Resolutions : HD 720p, 1080i, 1080psf (psf digital only), 1080p23.97/24/25/30, 1080p30, 1080p59.94, 1080p60; ED 480p, 576p; SD 625i (576i), 525i (480i); common VESA graphics formats from 640x480 to 1920x1200 (with reduced blanking for 1920x1200 and 1600x1200 modes). Applications • Professional AV • Corporate AV • Simulation • Fixed installs
