Kingst LA5032 USB Logic Analyzer 500M max sample rate, 32 Kanalen, 10B monsters, MCU, ARM, FPGA debug tool, Engels softw

You can download the software and user guide http www qdkingst com en ​LA5032 is a high performance logic analyzer with 32 channels and 500M sampling rate It is composed of two parts software on personal computer and hardware equipment It has the advantages of high sampling rate large sampling depth easy to use etc LA5032 can sample 32 digital signal at same time Then the sampled data can be displayed analyzed exported and saved on the computer Software can also decode the data if it conform to the standard protocol of the software supported Then the decoded data can be displayed exported and saved Features Portable and lightweight500M sampling rate full channelsLarge sampling depth and support compressionThe built in PWM generatorCompatible USB2 0 3 0 interfacePowerful software and easy to useSupport online upgrade automatically Specification Input channels number 32Max sampling rate 500MMeasurement bandwidth 80MMin pulse width can be captured 6 25nsHardware memory size 4GbitsHardware sampling depth 100M channelMax compressed depth 10G channelInput voltage range 50V 50VInput impedance 220KΩ 12pFAdjustable threshold voltage 4V 4V step 0 01VPWM channels number 2PWM frequency range 0 1 20MHzPWM frequency adjust step 10nsPWM pulse width adjust step 5nsPWM output voltage 3 3VPWM output impedance 50ΩStandby current 400mAMax operating current 480mASupport OS Windows XP Vista Windows 7 8 10 32bit 64bit Suppo
